WP30HDA-2V88 25hp 3inch Diesel Cast Iron Pump

Product Overview

The WP30HDA-2V88 is a 25 HP diesel-engine cast iron pump with inlet and outlet of 80 (3"), delivering up to 42 m3/h at 98 m head and self-priming to 7 m suction. The single-cylinder, vertical, 4-stroke air-cooled engine has a 2-88X79 mm bore x stroke and 961 cc of displacement, with 25 HP output. The fuel tank holds 12.5 L, the oil sump 2.8 L, and the unit measures 980X620X690, weighing 140 kg gross.

Key Features

• 42 m3/h at 98 m head: the WP30HDA-2V88 moves 42 cubic metres per hour up to 98 metres of head, which is the working point to size pipe diameter and hose length against.
• 80 (3") inlet and outlet, 7 m suction lift: self-priming to 7 metres, so the pump primes from a tank, canal or shallow sump rather than needing to be flooded below the water line.
• 25 HP diesel engine, 2-88X79 mm bore x stroke in 961 cc: single-cylinder, vertical, 4-stroke air-cooled, delivering 25 HP, which is what keeps this size pumping rather than straining at the duty point.
• 12.5 L tank, 2.8 L oil, 140 kg gross, 980X620X690: starting is by electric. One self-contained unit — no separate generator, no mains supply.

Applications

The WP30HDA-2V88 is built for abrasive and gritty water where an aluminium alloy pump would wear out. It is supplied to irrigation contractors, agricultural machinery dealers, mining and construction pump builders, and water contractors who need a 25 HP diesel driven pump. For trading companies, distributors and project buyers, WP30HDA-2V88 is an economical factory-backed option with steady supply and consistent quality.

Why Choose KIGERPOWER

KIGERPOWER (Ningde Kinger Electrical Machinery Co., Ltd.) has manufactured generators, engines and water pumps in Ningde, Fujian since 2006. Products are exported to 80+ countries and regions, backed by CE, SONCAP and ISO 9001 certification. Every unit is tested before shipment, and OEM/ODM programs are available with custom colors, branding, voltage and frequency settings. With factory-direct pricing and responsive after-sales support, KIGERPOWER is a reliable partner for distributors, dealers and end customers worldwide.

Learn more about our 12,000m² factory, 100% pre-shipment load testing, and international certifications on our About Us page.

FAQ

How much flow and head does the WP30HDA-2V88 deliver?

Up to 42 m3/h at 98 m total head, with 7 m maximum suction lift. Head falls as flow rises, so size the pump against the highest point you need to lift water to, and allow for friction loss in the pipe run.

Which engine is fitted, and what fuel does it run on?

A 25 HP single-cylinder, vertical, 4-stroke air-cooled diesel engine with 2-88X79 mm bore x stroke and 961 cc of displacement, giving 25 HP output. It runs on light diesel oil, with a 12.5 L tank.

How is it started, and what servicing does it need?

Starting is by electric. The oil sump holds 2.8 L and the fuel tank 12.5 L. Prime the pump chamber with water before every start so the mechanical seal does not run dry — for a 4-stroke engine, change the oil at the interval we specify for your duty cycle.

What size is the WP30HDA-2V88, and how much does it weigh?

The bare pump measures 980X620X690 and weighs 140 kg gross. Pallet size, container loading plan and the 20ft/40HQ quantities are available on request — they depend on packing.

What kind of water is this pump suited to?

The WP30HDA-2V88 is a cast iron pump intended for abrasive and gritty water where an aluminium alloy pump would wear out. The cast iron body and impeller tolerate grit and abrasive solids that would wear an aluminium alloy pump quickly.

Representative photo of the Cast Iron Pump range (model WP30HDA-2V88 shown). Current specification sheet and pricing on request.
